Meyer Sound X40

Meyer Sound ULTRA X40

The ULTRA-X40 brings the technology breakthroughs in our flagship line arrays to a versatile, compact loudspeaker. Its innovative concentric-driver configuration couples two 8-inch cone drivers to a rotatable waveguide surrounding a 3-inch high-frequency compression driver, to deliver smooth response across its entire range and directional control down to 400 Hz.

The ULTRA-X40 breaks new ground in power-to-size performance, thanks to its ultra-efficient 3-channel Class D amplifier that provides peak output of 1,950 watts with a max sustained current draw of just 1.3 A (230 V AC). All this in a speaker that's just 12.5 by 22 by 14 inches and less than 55 pounds—20 pounds lighter than its predecessor, the UPA-1P.

Two horn options give you total flexibility in system design. The ULTRA-X40’s precisely-tuned, rotatable 110° x 50° Constant-Q horn delivers uniform response throughout its coverage area. Need more focused coverage? Choose the ULTRA-X42 variation, which offers a narrower 70° x 50° pattern.

Meyer Sound ULTRA X40 Image
Meyer Sound ULTRA X40 - Highlights

The Meyer Sound ULTRA X40 is Meyer's iconic point source loudspeaker. The ULTRA X40 provides crystal clear output and incredibly high quality. The

Last updated May 2025

Watch Video
Meyer Sound ULTRA X40 Image
Meyer Sound ULTRA X40 - Unboxing

Here's a close up look at the unboxing of the Meyer Sound Ultra X40 active loudspeaker. The ULTRA-X40 brings the technology breakthroughs in

Last updated May 2025

Watch Video
Meyer Sound Ultra X40 Image
Club Sound System: Meyer Sound X40 / X42

For this night club sound system we used the weatherized Meyer Sound 900 LFC subwoofers (single 18") and the X42 tops (X40). This

Last updated May 2025

Watch Video
Meyer Sound 900 LFC Image
Meyer Sound Ultra X40: Live Music & Reactions

We used our new Meyer Sound ULTRA X40 tops with the 900 LFC 18" subwoofers for a live music gig in San Antonio. We interviewed some of the

Last updated May 2025

Watch Video

Meyer Sound ULTRA X40 Overview

The ULTRA-X40 brings new versatility to system design and deployment. It’s at home in any portable or installed application requiring predictable, controllable wide coverage, from concert halls and clubs to houses of worship, theatrical sound reinforcement, theme parks, stadiums, and nightclubs. It’s perfect for frontfill and under balcony use and in portable A/V systems and small voice-reinforcement systems.

If you can dream it, you can install it, with ULTRA-X40’s flexible rigging and mounting options. An integral handle can be used for portable applications or removed for permanent installation; 11 integral M8 points and an integral 35 mm pole-mount receptacle broaden the possibilities. Optional rigging accessories include an adjustable pole with M20 slug, a U-bracket, a yoke, a pinnable link on a channel for hanging multiple units from a single pick-up point, and cluster plates for versatile loudspeaker grouping.

The ULTRA-X40’s internal signal processing includes electronic crossover management, phase and frequency response correction filters, and driver protection circuitry. It all adds up to ultra-flat amplitude and phase response for exceptional impulse response and precise imaging.

ULTRA-X40 is equipped with Meyer Sound’s Intelligent AC, which auto-selects correct operating voltage, suppresses high-voltage transients, filters EMI, and provides soft-start power-up.

Don’t leave system management to chance: Optional RMS remote monitoring lets you keep a close eye on loudspeaker parameters from a Windows or Mac computer.

The ULTRA-X40’s trapezoidal enclosure is crafted from premium multi-ply birch with a finely textured finish. A powder-coated, perforated steel grille protects the driver elements. Full weather protection and custom color finishes are also available.
